54.30 ONE - FORWARD-THINKING DESIGN WITH SIGNIFICANT IMPACT
Discover the revolutionary ONE stock design for ANSCHÜTZ small bore actions 54.30 - The upgrade for your .22 l.r. target rifle! Level up to a modern aluminum stock and reach new athletic heights with your familiar barreled action. With modern, futuristic elegant design and optimal comfort, the ONE stock offers flexibility and precision simultaneously. Enjoy the unique balance of this stock, combined with the vibration behavior which is unique to aluminum stocks, and close to the classic wooden stocks. This is achieved by clamping the action with only one high-strength synthetic clamping sleeve, which evenly absorbs and dissipates vibrations.
The new ANSCHÜTZ Target small bore barreled action 54.30 is the further development of the legendary ANSCHÜTZ Match 54 barreled action. Barreled action 54.30 combines new ideas and requirements from the modern target shooting with components that have been tried and tested for decades.
The basis for the new development is the well-known and proven Barreled action Match 54.
The ejection window has been moved back by 30 mm and reduced in size by 18%. This improves the ergonomics when shooting and increases the stiffness of the case by 33%.
The bolt and the firing pin were shortened by 30 mm.
The weight of the firing pin has been reduced, thus reducing the locktime with the same force of the firing pin spring.
The shooting performance is further improved by the newly developed match cartridge bearing.
In the Barreled action Match 54.30, the barrel is screwed deeply into the sleeve in order to distribute the tension created in the joint as evenly as possible and over a large area.
Maintenance-friendly and durable overall construction, as usual with ANSCHÜTZ.
ANSCHÜTZ triggers are known worldwide for their quality. The trigger 5018, which breaks like glass, leaves nothing to be desired. With a set trigger weight of 125 g, this trigger leaves our factory in Ulm. The trigger weight can be adjusted from 60 g - 490 g to suit your individual needs. The trigger blade can be moved, swivelled and adjusted in height. There is nothing better!
The forward-thinking design of the ONE stock enables seamless integration of an existing 54.30 barreled action and can be perfectly adapted to it. A self-centering synthetic clamping sleeve connects the stock and barreled action and ensures a unique and always consistent vibration behavior - similar to a wooden stock! In addition, many existing ONE air rifle stock accessories can be fitted to the rear stock. It is also possible to fit the complete ONE air rifle rear stock! The grip can be selected in sizes S, M and L via the configurator.
The ONE stock concept allows the KK-Barreled action to swing comfortably from shot to shot. The high-strength, self-centering plastic collet holds the Barreled action securely in the action carrier, and transmits the vibrations from the ready to fire evenly to the stock - for an always even and smooth swinging action, which is unique in the aluminumstocks range.
The core of the rear stock is made of high-quality steel. This creates a counterweight to the fore-end, which balances it perfectly. The rear stock is offset by 20 mm, allowing the rifle to be brought even closer to the body.
The ONE stock comes with the familiar PRECISE butt plate extension. This offers the familiar and proven options for mounting a wide range of butt plates from all well-known manufacturers. Existing PRECISE butt plates or ANSCHÜTZ butt plate 4765 (formerly 2213-8700) can also be fitted without any problems.
The red safety ring enables a positive fit with the rear stock. This makes it easy to mount the cheek piece quickly and with repeat accuracy. The advantage of this safety ring is obvious: a complete cheek piece can be purchased and perfectly adjusted for each shooting position. Thanks to the positive fit, the safety ring guarantees that the various cheek pieces are always positioned consistently without having to make any changes to the cheek piece itself.
Thanks to the lowest possible connection of the hand stop close to the barrel axis, the shooter has even better control in the prone position. Thanks to this design, the fore-end can be fully gripped. This ensures even more stability and a more relaxed shooting position.
The following items are always included in the delivery, regardless of how you configure the product!
Transport rifle case MEGA
VARIO-palm rest 4844
ONE-hand stop
PRECISE butt plate carrier
Quick couplers adapter
Assembly instructions
Tool set
Quality control card with original test fire group
Delivered WITHOUT sight set and WITHOUT buttplate! Sight sets and butplates see accessories!
Pictures are with accessories, that aren't included in the delivery!
License required! Sale only to persons with a license for purchase.
